Ranges: -0.1KPa~0KPa~250Mpa
Combined error: ±0.25%FS; ±0.5%FS
ZPT510 output :4~20mA, 0~5V, 0~10V; 0.5~4.5
ZPS510 out put: 2.mV/V ；2.5mV/V ；3.33mV/V,100mV/V
Input voltage: 24(10~36) VDC, 5VDC
Operating temperature: -20℃~120℃
Zero blance:+/-5.0% Full scale
Over pressure: 1.5×FS
Electric connection: Shield cable or Hirschmann connector or customized
Process connection: G1/4, M20×1.5, 1/4NPT (Customized)
Cover material: 304,316 stainless steel
